Best Low Beam LED Headlight Bulbs for 2015-2017 Ford F150

If you’re looking to upgrade the factory halogen headlights on your 2015-2017 F150 and don’t want to dish out $2000 for Morimoto headlights but still want good light output then this article is for you.

There is not much room for the low beam bulbs on the 2015-2017 F150 headlights so options are limited. For example the GTR Lighting Ultra 2.0 LED bulbs will NOT fit the low beams. There are really only 2 bulbs that will fit properly fit in the low beams that still allows for the factory dust cap to be installed properly; the H11 GTR Lighting CSP Mini LED Bulbs and the H11 Diode Dynamics SL2 Pro LED Bulbs.

We tested the H11 GTR Lighting CSP Mini LED Bulbs against the H11 Diode Dynamics SL2 Pro LED Bulbs.

Brightness Results:
The OEM Philips H11 halogen bulb produced 470 maximum lux in our test.
The H11 GTR Lighting CSP Mini LED bulb produced 1400 maximum lux in our test.
The H11 Diode Dynamics SL2 Pro LED bulb produced 2600 maximum lux is our test.
(Note: These lux numbers only apply to this specific test when all variables are the same; headlights, power supply, distance from wall etc.)

Observations:
The SL2 Pro produced a much brighter and more controlled beam pattern compared to the CSP Mini bulbs. The beam pattern of the SL2 Pro bulbs is almost identical to the halogen bulb but is also over 5 times brighter which is very impressive.

The color of the SL2 Pro bulbs was also a much nicer pure white 5000K color temperature compared to the CSP Mini LED bulbs which are a slight hint of purple in the white color.

Conclusion:
We would highly recommend the H11 Diode Dynamics SL2 Pro LED Bulbs to upgrade the low beams on a 2015-2017 Ford F150. You can also upgrade the high beams at the same time with the 9005 Diode Dynamics SL2 Pro LED Bulbs.
