High Beam: Morimoto Mini HB LED

$170.00 CAD

COMPATIBILITY
APPLICATIONS: Universal (Cars, trucks etc)
DIRECT FITMENT: 9005, 9006, H7, H11 housings (little/no mods)
MODS REQUIRED: H1, H3 housings
OUTPUTS: High Beam
SHROUDS: All Styles
CENTRIC RINGS: Required for full-size shrouds

WHAT’S INCLUDED
PROJECTORS: 2x Morimoto Mini HB LED High Beams
HARDWARE: Threaded Shaft Mounting Kit
WIRING: Standard 9006 +/- inputs/connectors
WARRANTY: 2 Years

100-guarantee-seal-1 product-tag4 ssl-secure

Need help? 24/7 Chat Available!
SKU: N/A Categories: , Tags: , ,

Description

MORIMOTO: The Automotive Lighting Benchmark. While there’s probably nothing wrong with your halogen high beam bulbs, or certainly a retrofitted set of bi-xenon/Bi-LED projectors, overkill is under-rated, and that’s why we’re giving two thumbs up to the new Morimoto high beam projector.

WELL DONE: The Morimoto Mini HB projector is a projector designed as a dedicated high beam, and it is stupid bright! It has one job, and it is good at it!

EASY INSTALL: The Mini HB features a threaded-shaft style mount on the back that allows the projectors to be locked on with their included hardware, and minimal modifications to your headlight. Best part is that the threaded shaft is about twice as long as what you would normally find on something like a Mini H1 projector, making it even easier to install across the board. Not only that, it includes adapter hardware for most popular bulb sockets (h11, 9005, H7, etc)…Now that’s awesome.

SHROUDS: Conveniently, the Morimoto HB LED LED projectors are compatible with most every existing shroud on the market, even including the “Mini Series” – which will screw onto the pre-existing mounting points. They also take all shrouds that work with centric rings too- so you should be able to snap them right onto the bezel on the front face of the Hi-Lens.

WIRING Really doesn’t get any more simple. These come out of the box with a universal 9005/9006 male input that will connect directly to the high beam trigger (or splitters) coming from your car. If you have a differently sized OEM high beam bulb, no worries, just pick up an inexpensive adapter (which we also carry)

TECH SPECS
HEIGHT: 78mm
WIDTH: 82mm
PROJECTOR DEPTH: 100mm
MAX DEPTH: 125mm (includes shaft / wire exit)
LENS DIAMETER: 70mm/2.8
POWER: 25w (High Beam)
HIGH BEAM CURRENT: 1470mA
LUMINOSITY: 3000lm (combined)
LED TYPE: SSC
MOUNTING SHAFT: Diameter = 20mm
LOCK NUT: Size = 26mm
HOUSING DEPTH: 100mm Minimum
STANDARD LENS: 100% clarity performance-optic
